71802C DBL P4 Angular Contact Ball Bearing (15x24x5mm) Machine Tool Chinese High Speed Motor Bearing Made in China

71802C DBL P4 Angular Contact Ball Bearing (15x24x5mm) Machine Tool Chinese High Speed Motor Bearing Made in China

71802C DBL P4 Angular Contact Ball Bearing (15x24x5mm) Machine Tool Chinese High Speed  Motor Bearing Made in China

Product Details:

Place of Origin: CHINA
Brand Name: TLANMP
Certification: ISO9001:2008
Model Number: 71802C

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 1-1000
Packaging Details: Industrial Neutral Packing
Delivery Time: 10 days
Payment Terms: PAYPAL . T/T , WU , AliPAY
Supply Ability: 1000 pcs/month
Contact Now
Detailed Product Description
High Light:

71802C ball Bearing

,

15x24x5mm bearing

,

71802C bearing

71802C DBL P4 Angular Contact Ball Bearing (15x24x5mm)

Machine Tool Bearing Chinese High Speed Motor Bearing Made in China

A . Angular Contact Ball Bearing Parameters
Brand-TMP
Structure-Angular Contact ball
Model number-71802C AC/C
Inner ring(mm)-15
Outer ring(mm)-24
Width(mm)-5
Weight(Kg)-0.007
Materials-Chrome steel/GCR15
Precision grade-P4/P2
Lubrication type-Grease lubrication
Contact Angle-C=15°;AC=25°
Material(Ball)-Steel ball(SUJ2); SN24:Ceramic ball(Si3N4)
Number of Row-Single rows
Material(Cage)-TYN-PA;TR-PF
Combination of mark-SU:Universal combination (single row)
DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
Preloaded mark-EL: Micro preloaded
L : Light preload
M : Medium preloade
H : Heavy preloaded
B . 71802C Angular Contact Ball Bearing Specification Sheet
Model NumberDimensionsα=15°α=25°Material
(Cage )
Weight (kg)
Approx
Limiting speedLimiting speed
dDBBasic load
rating
LubricationBasic load
rating
Lubrication
Cr CorGrease OilCr CorGrease Oil
71802C152452.2 1.859000 890002.1 1.753000 79000PF0.007

Categories:Angular Contact Ball Bearings
Ceramic Ball Bearings
Related Search:71802C DBL P4,71802C Motor Bearing,71802C Angular Contact Ball Bearing,71802C Spindle bearing,15x24x5mm bearing
C . 718 series Angular Contact Ball Bearing Details

Product

Features

Precision Angular Contact Ball BearingsDue to their internal design, angular contact

ball bearings can withstand high radial-axial loads and reach high speeds.

They are asymmetrical for manufacturing reasons and can withstand unidirectional

axial loads only. Angular bearings are usually mounted in a group of two or more

opposed preloaded units with rigid or elastic spacers. Typically, the inner and

outer raceways and balls are made of chrome steel. Where operating conditions are

severe, bearings may have ceramic balls creating a hybrid bearing.

Series

Introduction

ISO 18 Series - highest speed, lowest load bearings-718 Series Angular Contact

Bearings

Series

Model No.

71800C 71801C 71802C 71803C 71804C 71805C 71806C 71807C 71808C 71809C 71810C

71811C 71812C 71813C 71814C 71815C 71816C 71817C 71818C 71819C 71820C 71821C

71822C 71824C 71826C 71828C 71830C 71832C 71834C 71836C 71838C 71840C 71844C

71848C 71852C 71856C 71860C 71864C 71868C 71872C 71876C 71880C 71884C 71888C

71892C 71896C 718/500C

ApplicationsAngular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrial equipment.
