Place of Origin: | China |
Brand Name: | TMP |
Certification: | ISO9001:2008 |
Model Number: | CSK30-2RS |
Price: | 1-1000 |
---|---|
Packaging Details: | Industrial Neutral Packing |
Delivery Time: | 10 days |
Payment Terms: | T/T |
Supply Ability: | 1000 pcs/month |
Minimum Order Quantity: | 1 |
High Light: | Sprag Clutch,One Way Clutch,One Way Bearing |
---|
CSK30-2RS One Way Clutches Sprag Type (30x62x16mm) One Way Bearings Freewheel Type Backstop Clutch | ||||||||||
A . One Way Clutches Sprag Type Parameters | ||||||||||
Brand- | TMP | |||||||||
Model number- | CSK30-2RS | |||||||||
Inner ring(mm)- | 30 | |||||||||
Outer ring(mm)- | 62 | |||||||||
Width(mm)- | 16 | |||||||||
Weight(Kg)- | 0.21 | |||||||||
Drag torque(Nm)- | 110 | |||||||||
Materials- | GCR15 | |||||||||
Series- | CSK | |||||||||
Lubrication type- | Grease/oil | |||||||||
Clutch type- | Sprag | |||||||||
Precision- | P0 | |||||||||
Structure- | Type CSK is a sprag type freewheel integrated into a 62 series ball bearing (except sizes 8 and 40). | |||||||||
B . CSK30-2RS One Way Clutches Sprag Type Specification Sheet | ||||||||||
Model Number | Size(mm) | Corresponding bearing | Drag torque | Speeds | Bearing Load Rating(KN) | Weight (kg) | Friction TR (Ncm) | |||
d | D | L | TKN1 (Nm) | n (r/min) | dyn | stat | ||||
CSK30-2RS | 30 | 62 | 16 | - | 110 | 4200 | 11.7 | 6.45 | 0.21 | 4.4 |
C . CSK Series One Way Clutches Sprag Type Details | ||||||||||
Product Features | One Way Clutches Sprag Type mainly used as Backstop clutches(Most suitable as backstops, and mostly the contact-free versions); continuously during operation. The freewheel prevents reverse rotation if the drive is disconnected. | |||||||||
Series Introduction | Type CSK is a sprag type freewheel integrated into a 62 series ball bearing (except sizes 8 and 40). It is bearing supported, delivered grease lubricated and protected against dust of more than 0,3 mm. The use of additional "nylos" type seals is recommended especially when the working temperature exceeds 50°C. Oil bath lubrication is also possible. several times the overrunning life time. Torque transmission is ensured by a press fit assembly into a rigid outer housing with N6 tolerance, and onto a shaft with n6 tolerance. The initial bearing radial clearance is set at C5, and is reduced if using the press fit as specified. | |||||||||
Series Model No. | CSK8(CSK8P/CSK8PP) CSK12(BB12/ZZ6201/OW6201/CSK12P/CSK12PP) CSK15(BB15/ZZ6202/OW6202/CSK15P/CSK15PP) CSK17(BB17/ZZ6203/KK17/OW6203/CSK17P/CSK17PP) CSK20(BB20/ZZ6204/KK20/OW6204/CSK20P/CSK20PP) CSK25(BB25/ZZ6205/KK25/OW6205/CSK25P/CSK25PP) CSK30(BB30/ZZ6206/KK30/OW6206/CSK30P/CSK30PP) CSK35(BB35/ZZ6207/KK35/OW6207/CSK35P/CSK35PP) CSK40(BB40/CSK40P/CSK40PP) CSK8-2RS CSK12-2RS CSK15-2RS/BB15-2GD CSK17-2RS/BB17-2GD CSK20-2RS/BB20-2GD CSK25-2RS/BB25-2GD CSK30-2RS/BB30-2GD CSK35-2RS/BB35-2GD CSK40-2RS/BB40-2GD | |||||||||
Applications | Reducers , Flender Gearbox ,SEW Gearbox; Overrunning clutch:for multiple-machine drives or to separate the inertia of masses of a driven machine from the driving machine after it has been switched off. Indexing clutch:which turns a shaft step by step, thus achieving indexed material feed or a variable speed. Backstop clutch:to prevent a machine shaft turning backwards. In this case the overrunning clutch acts as a brake. |
