HFL2530 One Way Clutches Roller Type (25x32x30mm) Drawn Cup Roller Clutches Stieber Freewheel Clutch

HFL2530 One Way Clutches Roller Type (25x32x30mm) Drawn Cup Roller Clutches Stieber Freewheel Clutch

HFL2530 One Way Clutches Roller Type (25x32x30mm) Drawn Cup Roller Clutches Stieber  Freewheel Clutch

Product Details:

Place of Origin: China
Brand Name: TMP
Certification: ISO9001:2008
Model Number: HFL2530

Payment & Shipping Terms:

Price: 1-1000
Packaging Details: Industrial Neutral Packing
Delivery Time: 10 days
Payment Terms: T/T
Supply Ability: 1000 pcs/month
Minimum Order Quantity: 1
Contact Now
Detailed Product Description
High Light:

Overrunning Clutch

,

One Way Clutch

,

One Way Bearing

HFL2530 One Way Clutches Roller Type (25x32x30mm) Drawn Cup Roller Clutches Stieber Freewheel Clutch
A . One Way Clutches Roller Type Parameters
Brand-TMP
Model number-HFL2530
Inner ring(mm)-25
Outer ring(mm)-32
Width(mm)-30
Weight(Kg)-0.044
Drag torque(Nm)-66
Materials-GCR15
Series-HF
Lubrication type-Grease/oil
Clutch type-Roller
Precision-P0
Structure-Drawn cup roller clutches HF(roller pin coupling),HFL(coupling and bearing assembly);
B . HFL2530 One Way Clutches Roller Type Specification Sheet
Clutch DesignationCorresponding disignationsBorndary Dimensions(mm)Torgue
Ma
Limiting Speed(rpm)Suitable
Drawn Cup Bearings
Weight
(g)
Steel SpringsPlastic
Springs
INANSKFwDCNmRotating
Shaft
Rotating
Outer Ring
HFL2530--HFL2530FCB-252532306655005500--44
C . HF Series One Way Clutches Roller Type Details

Product

Features

One Way Clutches Roller Type mainly used as Overrunning and Indexing clutches,
Overrunning clutches:The freewheel disengages automatically when the driven member

rotates faster than the driving member.
Indexing clutch:The freewheel allows the conversion of reciprocating motion into a discontinuous

rotational movement.

Series

Introduction

One way clutch-drawn cup roller clutches /clutch and bearing assemblies, It may take the switch,

the prevent returning installment, the overdrive clutch. HF(roller pin coupling): Is composed of the

drawn cup and the plastic retainer; The retainer may bring the plastic reed also to be possible on

the stainless steel reed guidance roller pin, in the addendum circle incline roller conveyer and the

roller pin takes the locking arrangement. HFL(coupling and bearing assembly):

The supporting bearing installs in the roller pin coupling's both sides and withstands the radial load,

those who take the supporting bearing is the roller pin and the plastic retainer module.

Series

Model No.

HF0612/FCS-6 HF0612R HF061210 HF0812 HF0812R HF061210 HF081410 HF081610 HF081412 HF1012/FCL-10K HF1012R HF1216/FC-12 HF1416 HF1616/FC-16 HF1816 HF2016/FC-20 HF2520/FC-25 HF3020/FC-30 HF3520/FC-35 HFL0822/FCBL-8K HFL1022 HFL1226/FCB-12 HFL1426 HFL1626/FCB-16 HFL1826 HFL2026/FCB-20 HFL2530/FCB-25 HFL3030/FCB-30 HFL3530
ApplicationsReducers , Flender Gearbox ,SEW Gearbox;
Overrunning clutch:for multiple-machine drives or to separate the inertia of masses of a driven machine from the driving
machine after it has been switched off.
Indexing clutch:which turns a shaft step by step, thus achieving indexed material feed or a variable speed.
Backstop clutch:to prevent a machine shaft turning backwards. In this case the overrunning clutch acts as a brake.
