|Place of Origin:||China|
|Minimum Order Quantity:||1|
|Packaging Details:||Industrial Neutral Packing|
|Delivery Time:||10 days|
|Payment Terms:||T/T,Paypal,Western Union,Escrow|
|Supply Ability:||1000 pcs/month|
|Angular Contact Ball Type:||KF400AR0||Deep Groove Ball Type:||KF400CP0|
|Four-Point Contact Ball Type:||KF400XP0|
|C . Type A-KF/Type C-KF/Type X-KF series Reail-silm Thin-section bearings Details|
To support various load scenarios,Reail-SlIM Thin section ball bearings are available in three basic types: radial contact
(type C), angular contact (type A), and fourpoint contact (type X) and in a variety of sizes ,or series (e.g., KA, KB, KC,
etc.). Reail-SlIM Thin section ball bearings are available with various separator options to space the rolling elements
uniformly and prevent contact between them.
Applications in Robotics, inspection equipment, satellites, cameras… anywhere precise positioning and lightweight
designs are critical.
|C . Type A-KF/Type C-KF/Type X-KF series Reail-silm Thin-section bearings 3 types|
Open REALI-SLIM Bearing Selections Type A Angular Contact, Snapover assembly permits use of a onepiece circular pocket ring
separator and greater ball complement. These bearings will accept radial load and single direction thrust load and are
normally used in conjunction with another bearing of similar construction. Type A bearings require the application of thrust
to establish contact angle.
A Conrad assembled bearing designed primarily for application of radial load—deep ball grooves also permit application of
thrust load in
Standard bearing lines are most often designed to handle either radial or axial load conditions. The unique feature about
the REALI-SLIM Type X four-point contact bearing line is that the gothic arch geometry of the inner and outer races
enables a single bearing to carry three types of
single fourpoint contact bearing can often replace two bearings, providing a simplified design.
stiffness or zero free play. This is accomplished by using balls that are larger than the space provided in the
raceways. The balls and raceways, therefore, have some elastic deformation in the absence of an external load
|C . Type A-KF/Type C-KF/Type X-KF series Reail-silm Thin-section bearings Model Number|
