M74D-20 Burgmann Mechanical Seals (20x35x61mm) |M74-D Multiple springs Unbalanced Seals

M74D-20 Burgmann Mechanical Seals (20x35x61mm) |M74-D Multiple springs Unbalanced Seals

M74D-20 Burgmann Mechanical Seals (20x35x61mm) |M74-D Multiple springs Unbalanced Seals

Product Details:

Place of Origin: CHINA
Brand Name: TLANMP
Certification: ISO 9001:2005
Model Number: M74D-20

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: $1~$500
Packaging Details: Industrial neutral packaging (Paper Box)
Delivery Time: 1-3 day after Payment
Payment Terms: T/T,WU,Paypal,Alipay etc
Supply Ability: 1~1000 pieces per month
Contact Now
Detailed Product Description
Standard Or Nonstandard: Standard Style: Mechanical Seal
Material: Silicone


M74D-20 Burgmann Mechanical Seals (20x35x61mm) |M74-D Multiple springs Unbalanced Seals for Shaft Size 20mm Pumps
Series Burgmann Mechanical Seals M74-D
Model Number M74D-20
Shaft Size 20 mm
Introduction
Double seal;
Unbalanced;
Independentof direction of rotation;
Multiple springs;

Double seals in the M74D series have the same design-features as the “M7“ family of single seals (easy-to-replace seal faces, etc.). Apart from the installation length of the drive collar, all fittingdimensions (d1 <100 mm) conform with EN 12756.
Application
Date
Operation limits:
shaft size: 18-200mm
Temperature: -20°C~+180°C
Pressure: ≤1.6MPa
Speed: ≤20m/s
Materials
Burgmann type M7N Multi-Spring mechanical Seals Material
Stationary Ring (Carbon/SiC/TC)
Rotary Ring (SiC/TC/Carbon)
Secondary Seal (VITON/PTFE+VITON)
Spring & Other Parts (SS304/SS316)

M74D Mechanical sealM74D Mechanical seal
