RB4510UUCC0/P5 CRB4510 CRBC4510UUT1 NRXT4510 Crossed Roller Bearings (45x70x10mm) TLANMP made Robotic Bearing

Product Details:

Place of Origin:	CHINA
Brand Name:	TLANMP
Certification:	ISO9001:2008
Model Number:	RB4510 CRB4510 CRBC4510 NRXT4510

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	1-1000
Packaging Details:	Industrial Neutral Packing
Delivery Time:	10 days
Payment Terms:	PAYPAL . T/T , AliPAY, Western Union
Supply Ability:	1000 pcs/month

Contact Now

Detailed Product Description

Material:	GCr15 Bearings Steel	Application:	Robotic Arms, Machine Tool Turntable
Standard:	THK/INA/IKO

RB4510UUCC0 P5 Crossed Roller Bearings (45x70x10mm)...

US $75.63 / Set

Product Description

RB4510UUCC0 P5 Crossed Roller Bearings (45x70x10mm) Robotic Bearing-High precision Robotic arm use Japanese Bearing replace
A . Crossed Roller Bearings Parameters
Brand-	TLANMP
Model number-	RB4510UUCC0
Inner ring(mm)-	45
Outer ring(mm)-	70
Width(mm)-	10
Weight(Kg)-	0.17
Materials-	GCR15/GCR15SiMn
Precision grade-	P5/P4/P2
Lubrication type-	Grease lubrication
Rotating part-	Inner Ring Rotation
Load direction-	Multi-load
Structure-	Separable Outer Ring

B . RB4510 Crossed Roller Bearings Specification Sheet
Model Number	Main dimensions						Mounting dimensions		Basic load rating (radial)		weight
	Inner ring d (mm)	Outer ring D(mm)	Roller pitch circle dp(mm)	Width (mm)	Greasing hole φ	Chamfer r(min)	ds	Dh	C kN	C0 kN	Kg
RB4510	45	70	56.5	10	1	0.6	51	61.5	8.62	11.3	0.17

C . RB type Crossed Roller Bearings Details
Product Features	TMP Crossed roller bearings are lightweight, compact bearings with thinnest possible inner and outer rings with high rigidity, because of its vertical arrangement of cylindrical rollers with a 90°V groove through the separate spacers in the deep groove rolling surface. This special design allows just one bearing to carry loads in all directions including radial, axial and moment loads.
Series Introduction	RB standard type is a bearing with thinnest possible inner and outer rings because the outer ring is split while the inner ring is integrated into the main body. It is being used in cases where a high rotational accuracy of the inner ring is required.
Series Model No.	RB4010UUCC0 RB4510UUCC0 RB5013UUCC0 RB6013UUCC0 RB7013UUCC0 RB8016UUCC0 RB9016UUCC0 RB10016UUCC0 RB10020UUCC0 RB11012UUCC0 RB11015UUCC0 RB11020UUCC0 RB12016UUCC0 RB12025UUCC0 RB13015UUCC0 RB13025UUCC0 RB14016UUCC0 RB14025UUCC0 RB15013UUCC0 RB15025UUCC0 RB15030UUCC0 RB16025UUCC0 RB17020UUCC0 RB18025UUCC0 RB19025UUCC0 RB20025UUCC0 RB20030UUCC0 RB20035UUCC0 RB22025UUCC0 RB24025UUCC0 RB25025UUCC0 RB25030UUCC0 RB25040UUCC0 RB30025UUCC0 RB30035UUCC0 RB30040UUCC0 RB35020UUCC0 RB40035UUCC0 RB40040UUCC0 RB45025UUCC0 RB50025UUCC0 RB50040UUCC0 RB50050UUCC0 RB60040UUCC0 RB70045UUCC0 RB80070UUCC0 RB90070UUCC0 RB1000110UUCC0 RB1250110
Applications	Product Application •Industrial Robotic arm,Reducer drive •precision Turntable,NC rotary table •Rotation part of Machine tools •Inspection instrument,Medical equipment • Aviation equipment,Military radar etc
